6
PART IDENTIFICATION CHART
M8 x 70mm Carriage Bolt (20)
M8 x 70mm Bolt (24)
M10 x 45mm Screw (19)
M6 x 75mm Screw (18)
M6 x 16mm
Screw (15)
M8 x 75mm Bolt (17)
M8 x 80mm Bolt (27)
M8 Locknut (22)
M6 Curved
Washer (21)
M8 Curved
Washer (23)
M10 Curved
Washer (26)
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in
the hardware kit, check to see if it has been preassembled. Extra parts may be included.
