13
14
14. Press the Front Upright Cover (16) into the
Rear Upright Cover (3).
15. Press two Outer Leg Covers (20) together
around the Right Pedal Bracket (21) and the
Right Upper Body Leg (6).
Repeat this step on the other side of the
elliptical exerciser.
16
3
15
20
20
6
11
15
21
16. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet from damage, place a mat under the
elliptical exerciser.
