MT-7068 Maintenance Kit
Congratulations on your purchase of MT-7068 Pro'sKit All-in-one Toner & Probe Kit. The Toner and Probe
set is used to quickly trace and identify cables or wires within a group and also check the operation of
phone lines. With proper use and care, this meter will provide many years of reliable service.
Index
Features 3
Applications 3
Advanced Features 3
Unpacking 4
Safety Information 4
MT-7068-T Toner. 5
MT-7068-R Probe 6
Locating and Isolating Cables 7
Locating Individual Wire Pairs with the MT-7068 Analog Function 8
Isolating Cables 9
Cable Map Testing 10
Validating the Cable's Shield and Continuity Test 13
Validating Telephone Service and Polarity 14
Powering a Telephone Test Set 15
Validating Ethernet Service 16
Battery Life and Replacement 17
Replacing the Fuse 18
Maintenance 19
Trouble shooting 19
Specifications 20
The MT-7068 All-in-one Toner & Probe Kit let you locate, isolate, and validate twisted pair (UTP, STP, Cat
5e, Cat 6), coax cables (RG6, RG58, RG59, and others for CATV/CCTV), USB and A/V signal, bare wire
(such as speaker wire and security network wire), and Cat 3 telephone cabling. The Toner also lets you
validate voice and data services.
The MT-7068 All-in-one Toner & Probe Kit features let you use the Toner and Probe to validate and trouble-
shoot wiring on RJ11 /RJ45 cables and connectors, USB, F, BNC, and RCA connectors, and it also supplied
with alligator clips to work with. The MT-7068 Toner detects telephone and Ethernet service, indicates
polarity and active line numbers on voice circuits, and indicates active pair number on Ethernet circuits.
The MT-7068 Toner and Probe also provide standard functions such as visual and audible signal strength
indication, analog
toning/detection, and continuity testing.
The MT-7068 All-in-one Toner & Probe Kit is ideal for all maintenance fields of telecommunication, network-
ing, datacom, Audio/Video, cable TV, and all weather cabling, etc.
Overview
2
