PARTS LIST SX2000 / SX2100 UPPER
REF. STOCK CODE PART NO. DESCRIPTION QTY
1 E11787-P F11787-P SOLUTION TANK 1
2 E11870 F11788 RECOVERY TANK 1
3 E11791 F11791 LID, SOLUTION TANK 1
4 E11124 E11124 GASKET, RECOVERY TANK 1
5 12904A STAND PIPE ASSEMBLY 1
5A K11965 ELBOW, 180 DEG. FLOAT BALL 1
5B E00919 K00672 PVC PIPE, 1.5 X 12 IN, SCH 40 WHT 1
5C E10989A 10989-2A FLOAT BALL SCREEN 1
5D E00913-P K00741 ADAPTER 1
6 E11785 F11785 LID, RECOVERY TANK 1
7 C12039 WASHER ¼ X 1 SS 2
8 E02322 C02322 BOLT ¼ X 20 2
9 BE4901 B02218-1 POWER CORD 25FT & 13A PLUG SET 220-240V CE 1
10 E11177 C11177 VELCRO STRAP 1
11 H02548-2 LABEL IMPORTANT CORD 1
12 B00185-30 WIRE 73” 1
13 B00185-40 WIRE 73” 1
14 E010314 B010314 WIRE HARNESS 1
15 E11786B-NL F-11786-B-NL HANDLE 1
16 B00177 TERMINAL LUG 0.25 X 0.032 16-14 AWG FULLY INSULATED 2
17 B00185-40 WIRE BLACK 5” 1
18 E00295-1 C00295-1 SCREW NO.10 ¾” BLACK PHILLIPS 2
19 C00293 SCREW NO.8 ½” BLACK PHILLIPS 2
20 D11168 COVER SWITCHPLATE 1
21 E02211-1 B02211-1 ROCKER SWITCH, GREEN ILLUMINATED 230V 16A 3
22 H10911 LABEL EARTH SYMBOL 1
23 E010284 D010284 SWITCHPLATE 1
24 E010453 E010453 GASKET, SWITCHPLATE 1
25 B00177-1 TERMINAL LUG 0.25 X 0.032 4
26 B00185-30 WIRE WHITE 5” 1
27 C02315 LOCK WASHER NO.10 SS 2
28 C00264 NUT 10-32 1
29 E11141 C11141 SCREW, ALLEN HEAD 10-24 X 1.25” 8
30 E00665-1 K00665-1 HOSE ADAPTOR 1.5” BLACK 1
31 KP00427 E00427 GASKET, ADAPTOR & DRAIN VALVE 2” 2
32 C00313 HEX BOLT ¼ X 20 X ¾ 6
33 JE00233 C00233 WASHER FLAT ¼” 8
34 C02312 LOCK WASHER ¼” INT STAR 2
35 E010283 D010283 PLATE, HEATER MOUNTING 1
36 F11804 HEATER MOUNT 1
37 JE00261 C00261 NUT ¼ X 20 HEX 2
38 EN00711 K00711 DRAIN VALVE 1
E00711RK K00711-1 SEAL, DRAIN VALVE 2
39 EN00710 K00710 ELBOW DRAIN VLAVE 1
40 JE00254 C00254 LOCK WASHER ¼” SPLIT 2
41 E02294 C02294 SCREW ¼ X 20 X 1.25 2
42 E11185 K11185 ELBOW 1 ½” PVC 1
43 E00672-1 K00672-1 PVC PIPE 1.5” X 2.25” SCH 40 WHITE 1
44 E11129 E11129 GASKET BASE 5FT 1
45 CH00060 A00060 3/8 BARB X ¼ MP BRASS 1
46 E00052 A00052 BRASS ELBOW ¼ M-F 1
47 JE00255 C11244 WASHER ½” PLATED 1
48 E00124 A00124 HEX NUT ¼ MPT BRASS 1
49 EH00373 D00373 SOLUTION FILTER ¼” 1
50 C11143 ¼ X 20 X 1.5” SS PAN HEAD SS PHILLIPS 2
51 S11179 NON-SKID TAPE 1” ROLL 1
