PARTS LIST SX2000 / SX2100 BASE
REF. STOCK CODE PART NO. DESCRIPTION QTY
1 C00297 SCREW,#8 X .25 IN, PAN HEAD 1
2 J11863 HOSE, 3 IN 1
3 TT00639 J00639 SCREW CLAMP, 1.63 - 2.43IN. 3
4 E00618 J00618 VACUUM HOSE, 2IN GREY, WIRE, 22 IN LG 1
5 F11178-BLK INTERCOOLER, GALAXY, BLACK 1
6 LA4501E 117196-00 VACUUM MOTOR 230V 5.7” 3-STAGE W/CHOKE COIL
SX2000 POWERFLO
SX2100 POWERMAX
1
2
7 J00657 HOSE CLAMP, 2 IN SLDPRT 1
8 E00618 J00618 VACUUM HOSE, 2 IN GREY, WIRE, 4 IN LG 1
9 JE00261 C00261 NUT, .25-20, HEX 10
10 C00254 LOCK WASHER, 1-4IN SPLIT 1
11 D11134-1 PLATE,VACUUM BASE W-STUD 1
12 C11189 SCREW, 1-4 X 20 X 4.5 IN, HEX 5
13 C11516 SCREW, 1-4 X 20 X 4.5 IN, FLAT HEAD, PHILLIPS 1
14 C02312 LOCKWASHER, .25 IN., INTERNAL STAR 1
15 E11314 G11314 PRESSURE REGULATOR, 140 PSI 1
16 CH00060 A00060 3/8 BARB X ¼ MP, BRASS 1
17 E00052 A00052 .25 X .375 M-F 90 DEG BRASS 3
18 E00161 A00161 TEE, .25 FP, BRASS 1
19 CH00111 A00111 NIPPLE, .25 IN 2
20 CH00121 A00121 FITTING, .25 MP X .25 FP, BRASS 1
21 JE00255 C11244 WASHER, .56 X 1.5 X .05 2
22 GU00102 A00102 QD, .25F X .25FP, BRASS 1
23 RS4924 B11150 GROUND WIRE1.5MM GRN/YEL 3
24 C00302 RIVET, #41 SS 1
25 E00097-A A00097A CAP, INLINE FILTER 1
26 E00094E A00094E CHECK VALVE, NO STRAINER 1
27 A00094C CHECK VALVE BODY 1
28 E02322 C02322 HEX BOLT,1-4 X 20 X 1.75 IN 4
29 E010379 D010379 HEATER MOUNTING PLATE 1
30 C11440 SPACER, HEATER MOUNTING PLATE 4
31 E00061 A00061 3-8 BARB X 1-4FP, BRASS 1
32 E02564-2 H02564-2 LABEL, CAUTION, MOTOR HOUSING 1
33 C00293 #8 X .5IN PAN, BLACK SMS, PHILLIPS 10
34 RS00192 B00192 MOUNT, NYLON TIE 2
35 C02321 8-32 X .88 PAN HEAD 1
36 E02200 B02200 CABLE CLAMP, 1202AC 1
37 C00280 HEX NUT, 8-32 BLACK ZINC 1
38 E11199 B11199 STRAIN RELIEF, PIGTAIL 1
39 E10510 K10510 PLUG, 1.25 IN, BLACK 1
40 H03545 COVER, SERIAL # LABEL 1
41 E00565-13 H00565-13 LABEL, SERIAL NUMBER,CE 1
42 E11170 D11170 AXLE 1
43 E00240 C00240 WASHER, SHOULDER, NYLON 4
44 E010313 G11767 WHEEL, 10 IN 2
45 E02305 C02305 CAP NUT, .5IN PUSH-ON 2
46 E11431 FOAM, 7 X 4.5 IN 1
47 E11432 D11432 COVER, MUFFLER 1
48 E03251 C03251 WASHER, .187 ID, BACKUP 3
49 E11429 E11429 FOAM, 12 X 6.5 IN 1
50 E11430 E11430 FOAM, 14 X 6.5 IN 1
51 RS4924 B00185-61 WIRE, 16GA, GRN-YEL, DNO 1
52 C90011 HEX NUT, METRIC, 8MM X 1.25 1
53 JE00251 C00251 LOCKWASHER, .31, SPLIT 1
54 RS4910 B00182 RING TERMINAL, .375 CENTRE 1
55 E90001A B90001 FILTER, EMI-RFI, 250 VAC 1
56 RS4906 B00177 TERMINAL LUG, FEMALE, QD, .25 X .032, 16-14 AWG 4
57 H10914 LABEL, NEUTRAL 1
58 H10913 LABEL, LIVE 1
59 H10911 LABEL, EARTH SYMBOL 3
60 RS4918 WIRE, 1.5MM BLUE 6 IN 1
61 RS4919 WIRE, 1.5MM BROWN 6 IN 1
62 E00314-1 C00314-1 HEX BOLT, 1-4 X 20 X 1IN 8
63 JE00233 C00233 WASHER, FLAT, .25 IN 26
Steempro Manual.doc 1/8/09 Page 20 of 31
