Prochem Steempro 2000 - Parts List Sx2700; Sx2750 Base

PARTS LIST SX2700 / SX2750 BASE
REF. STOCK CODE PART NO. DESCRIPTION QTY
1 C00297 SCREW,#8 X .25 IN, PAN HEAD 1
2 J11863 HOSE, 3 IN 1
3 TT00639 J00639 SCREW CLAMP, 1.63 - 2.43IN. 3
4 E00618 J00618 VACUUM HOSE, 2IN GREY, WIRE, 22 IN LG 1
5 JE00273 C00273 LOCK NUT ¼-20 NYLON SS 16
6 F11178-BLK INTERCOOLER, GALAXY, BLACK 1
7 JE00233 C00233 FLAT WASHER ¼” 26
8 E00449 E00449 GROMMET 6
9 C00284 SCREW 10-32 X 0.375 EARTH 2
10 RS4924 B11150 EARTH WIRE GREEN / YELLOW 1.5MM 2
11 LA4501E 117196-00 VACUUM MOTOR 230V 5.7” 3-STAGE W/CHOKE COIL 2
12 J00657 HOSE CLAMP 2” SLDPRT 1
13 E00618 J00618 VACUUM HOSE 2” WIRE 4” 1
14 JE00261 C00261 NUT ¼ - 20 HEX 10
15 C00254 LOCK WASHER ¼ SPLIT 1
16 E11134 D11134 VAC PLATE 1
17 C11189 SCREW ¼ - 20 X 4 ½” HEX 5
18 C02312 LOCK WASHER ¼ INT STAR 1
19 C11516 SCREW ¼ - 20 X 4 ½” FLAT HEAD PHILLIPS 1
20 E11154 J11154 SOLUTION HOSE 3/8 X 31” WIRED 1
21 J11508 SCREW CLAMP NO.6 0.43” TO 0.875” 8
22 G11904 POWER PRIME (SX2750) 1
23 CH00060 A00060 3/8 BARB X ¼ MP, BRASS 1
24 E00053 A00053 45 ELBOW BRASS ¼ MP X ¼ FP 1
25 E13154 G13154 PRESSURE REGULATOR (SX2750) 1
26 E00052 A00052 90 ELBOW BRASS ¼ MP X ¼ FP 3
27 00580-13 HOSE ASSY 13” X ¼” HP 1
28 E00516-3 G00516-3 PRESSURE GAUGE 0 – 600PSI (SX2750) 1
29 JE00255 C11244 WASHER, .56 X 1.5 X .05 4
30 GU00104 A00104 MALE QUICK CONNECT ¼” BRASS 1
31 E00161 A00161 TEE BRASS ¼ FP 1
32 CH00111 A00111 ¼ NIPPLE BRASS 2
33 C00232 FLAT WASHER ½” 1
34 A00154 90 ELBOW BRASS ¼ NPT X ¼ NPT 1
35 E10691 K10691 PVC PIPE ¼” X 1 ½” SCH 80 4
36 C02291 SCREW ¼ - 20 X 2 ½” 4
37 E10379 D10379 HEATER MOUNTING PLATE 1
38 E11165 C11165 SCREW NO.8 X 1” PAN BLACK 5
39 F11790-1 COVER, HEATER TUNNEL 1
40 B11779 STUB 12-3 SJTW YELLOW 1
41 RS4907 B00191 NYLON TIE 11” 6
42 C00293 SCREW NO.8 X ½” PAN BLACK SMS PHILLIPS 6
43 RS00192 B00192 CABLE TIE HOLDER 3
44 E11199 B11199 CABLE STRAIN RELIEF 1
45 H03545 COVER, SERIAL LABEL 1
46 E00565-13 H00565-5 SERIAL LABEL 1
47 E02305-1 C02305 CAP NUT ½” PUSH-ON 2
48 E00240 C00240 SHOULDER WASHER NYLON 2
49 E010313 G11767 WHEEL 10” 2
50 E11170 D11170 AXLE 1
51 E11789-1 F11789-1 BASE 1
52 E02310 C02310 HEX BOLT ¼ -20 X 1 ¼” 8
53 E03518 G03518 CASTER WHEEL 4” 2
54 FJ44010
PC809147
E13161
R3C11242A
8090-945-270
300036
PUMP FLOJET TRIPLEX 100PSI 230V (SX2700)
PUMP SHURFLO 120PSI 230V (ALTERNATE SX2700)
PUMP 500PSI 230V (SX2750)
1
1
55 RS4906 B00177 TERMINAL LUG, FEMALE, QD, .25 X .032, 16-14 AWG 2
56 E03251 C03251 WASHER 3/16” 1
57 E00168 A00168 BRASS BUSHING 3/8M X 1/4”F 4
58 A90004 BARB, BRASS ½” X ¼” M 1
59 A00155 MALE PLUG ¼” NYLON 1
60 J11933 HOSE, ½” POLYWIRE PVC 32” 1
61 J00632 PULSE HOSE PUMP QD 42” 2
62 RS00190 B00190 NYLON TIE 4” 8
63 D13128 PUMP PLATE 500PSI (SX2750) 1
Steempro Manual.doc 1/8/09 Page 25 of 31
