Prochem Steempro 2000 - Parts List Sx2700; Sx2750 Upper

PARTS LIST SX2700 / SX2750 UPPER
REF. STOCK CODE PART NO. DESCRIPTION QTY
1 E11787-1 F11787-1 SOLUTION TANK 1
2 E11788-1 F11788-1 RECOVERY TANK 1
3 E11791-1 F11791-1 LID, SOLUTION TANK 1
4 E11167 C11167 SCREW ¼ - 20 X ¾ SS 6
5 E02714 K02714 PLUG 0.500 4
6 CH00060 A00060 3/8 BARB X ¼ MP BRASS 2
7 E00052 A00052 90 ELBOW ¼ M-F 3
8 JE00255 C11244 WASHER ½” PLATED 3
9 00580-16.5 HOSE ASSY. 16.5” X ¼” 1
10 E11836 E11836 LID GASKET 1
11 12905A STAND PIPE ASSY 1
11A K11965 ELBOW 180 1
11B E00919 K00672 PVC PIPE 1 ½” X 14 ¾” SCH 40 WHITE 1
11C E00913-P K00741 PIPE ADAPTER 1 ½” SCH 40 WHITE 1
11D E10989A 10989-2A FLOAT BALL SCREEN 1
12 E11785-1 F11785-1 LID, RECOVERY 1
13 BE4901 B11769 POWER CORD 25FT & 13A PLUG SET 220-240V CE 1
14 E11177 C11177 VELCRO STRAP 1
15 H02548-2 LABEL, IMPORTANT CORD 1
16 B00185-30 WIRE 73” 1
17 B00185-40 WIRE 73” 1
18 E010314 B010314 WIRE HARNESS 1
19 E11786-1 F11786-1 HANDLE 1
20 B00177 TERMINAL LUG 0.25 X 0.032 16-14 AWG FULLY INSULATED 2
21 B00185-40 WIRE 10” 14 GA BLACK UL1015 1
22 E00295-1 C00295-1 SCREW NO.10 ¾” BLACK PHILLIPS 2
23 C00293 SCREW NO.8 ½” BLACK PHILLIPS 2
24 D11168 COVER, SWITCHPLATE 1
25 E02211-1 B02211-1 ROCKER SWITCH ILLUMINATED GREEN 230V 16A 3
26 E010284 D010284 SWITCHPLATE 1
27 E010453 D010453 GASKET, SWITCHPLATE 1
28 B00177-1 TERMINAL LUG 0.25 X 0.032 4
29 B00185-30 WIRE WHITE 5” 1
30 C02315 LOCK WASHER NO.10 SS 2
31 C00264 NUT 10-32 1
32 E00288-1 C00288-1 SCREW ¼ - 20 X 2 ¼” C/S 4
33 E00288 C00288 SCREW ¼ - 20 X 1 ½” C/S 4
34 E00665-1 K00665-1 HOSE ADAPTER 1 ½” BLACK 1
35 EN00666 K00666 ELBOW 90 1 ½” WHITE 1
36 E00314-1 C00314-1 HEX BOLT ¼ X 20 X 1” ZINC 4
37 JE00233 C00233 ¼ FLAT WASHER 6
38 C00313 HEX BOLT ¼ X 20 X ¾ SS 2
39 C02312 ¼ LOCK WASHER INT STAR 2
40 E010283 D010283 PLATE, HEATER MOUNT 1
41 F11804 HEATER MOUNT 1
42 JE00261 C00261 NUT ¼ - 20 HEX 2
43 EN00710 K00710 ELBOW, DRAIN VALVE 1
44 EN00711 K00711 DRAIN VLAVE 1
45 KP00427 E11128 GASKET DRAIN VALVE 1
46 E12110 C12110 HEX BOLT 3/8” - 16 X 1 ¾” 2
47 E11540 C11540 WASHER 3/8” 2
48 E00913-P K00741 PIPE ADAPTER 1 ½” WHITE PVC 1
49 E00672-1 K00672-1 PVC PIPE 1 ½” X 2 ¼” SCH 40 WHITE 1
50 A90004 0.5” BARB X ¼ MP BRASS 1
51 EH00373 D00373 INLET FILTER 2
52 E00124 A00124 HEX NUT ¼ NPT BRASS 2
53 C11144 SCREW ¼ - 20 X 2” SS 2
54 S11179 NON-SKID TAPE 1” ROLL 1
55 E00448-1 C00238 WASHER 5/8 NEO STEEL SS 2
Steempro Manual.doc 1/8/09 Page 23 of 31
