PROEL NEXT User Manual

12
NEXT12BA / 12HBA / 15HBA / 8FBA
XLR balanced
2-positive / 3-n
egative / 1-gr
oun
d
XLR unbalanced
2-positive / 3-n
egative conn
ected to 1-gr
oun
d
JACK balanced
Tip-positive / Ring-negative / Sleeve-ground
JACK unbalanced
Tip-positive / Ring-negative connected
to Sleeve-ground
CONNETTORI Italiano CONECTORES EspañolCONNECTORS English
ESEMPI DI CONNESSIONE - CONNETTORI -CONFIGURAZIONI CONSIGLIATE
CONNECTION EXAMPLES - CONNECTORS - SUGGESTED CONFIGURATIONS
EJEMPLOS DE CONEXION - CONECTORES - CONFIGURACIONES ACONSEJADAS
4
5
6
1
2
3
HPC250
1)Tinned copper 22 AWG = 7 x 0,20mm (0,22mm
2
)
2)PE ø 1.36mm
3)Tinn
ed copper 24 A
WG = 7 x 0,20mm (0,22mm
2
)
4)Con
d
uctors: Spiral cotton filter
5)Cable: Tinned copper braid 6x16x0,10 mm > 95%
6)FLEXIBLE
PVC 60 shore ø 6.50 mm
1) 3) Bare copper
Power: 16 AWG = 3x29x0.25 mm (1.5 mm
2
)
Si
gn
al: 22 A
WG = 2x11x0.20 mm
(0.35 mm
2
)
2)
P
ower: PVC 60 shore ø 3.0 mm
4)Signal: PVC HT105 ø 1.50 mm
5)Spiral red copper 4x16x0.12 90%
6)CONDUCTORS - PVC 60 shore ø 4.00 mm
7)
CABLE - Fle
xible PVC 60 sh
or
e ø 10.80 mm
Com
-
plyin
g with CEI 20-20 r
egulations
CAVI CONSIGLIATI Italiano CABLES ACONSEJADOS EspañolSUGGESTED CABLES English
3
4
5
6
7
2
1
HPC501
