NEXT8FP
NEXT12P NEXT12HP NEXT15HP
System type
Nominal impedance (ohm) 4 – 8 4 – 8 4 – 8 4 – 8
Continuous power rating (AES standard) 160W 170W 300W 400W
Peak power rating 320W 340W 600W 800W
Frequency response @ ± 6dB 70Hz - 20KHz 65Hz - 20KHz 50Hz - 20KHz 50Hz - 20KHz
Sensitivity @ 1W/1m 96dB 97dB 98dB 98dB
Rated Maximum SPL 121dB 122dB 126dB 127dB
Low frequency device 8” woofer 12” woofer 12” neodymium woofer 15” neodymium woofer
2.5” voice coil 2.5” voice coil
High frequency device
Coverage dispersion angle
Crossover frequency (Hz) 3000 3500 2000 2000
Connectors
En
closure
Monitor taper 45°
Flying points
Dimensions (WxHxD cm) 28 x 41 x 24.5 41.5 x 61.5 x 37 41.5 x 61.5 x 37 48.2 x 70.5 x 44
Weight (Kg - lbs) 7.1 - 15.6 14 - 30.8 13 - 28.7 19.7 - 43.4
Options White colour - 70V/100V
Active version NEXT8FBA NEXT12BA NEXT12HBA NEXT15HBA
Continuous power 150W+50W rms bi-amp 170W+30W rms bi-amp 300W+100W rms bi-amp 400W+100W rms bi-amp
Frequency response @ ± 6dB 60Hz - 20KHz 65Hz - 20KHz 50Hz - 20KHz 40Hz - 20KHz
Line Input impedance
Line Input Sensitivity
Mic Input impedance
Mic Input Sensitivity
Connectors Combo®/ XLR F/ XLR M
Cooling
Flying points 2xM8
Max Power consumption 300VA 300VA 480VA 600VA
Weight (kg - lbs) 9.7 - 21.5 18.5 - 40.8 18 - 39.7 25.4 - 56
13
DATI TECNICI
TECHNICAL DATA
DATOS TECNICOS
NEXT SERIES
Tutte le specifiche possono essere cambiate senza alcuna notifica.
All specification subject to change without notice.
Todas las especificaciones están sujetas a cambio sin previo aviso.
2xSPK4MP linked
injection reinforced hi density polypropylene
45° with optional metal bracket
Jack/ 2 x XLR F/ XLR M
3xM8
1” compression driver
90°H x 60°V
20kohm balanced 10kohm unbalanced
-6 dBu to 0 dBu for full output
2kohm balanced 1kohm unbalanced
max -42 dBu
natural convection + vented cooling system (safety protection 65°C)
3xM8
2-way vented passive enclosure
1” throat - 1.4” voice coil compression driver
