13
Powered version
Max power
160W IHF
Continuous power
120W EIA (RMS)
Input impedance 20kΩ balanced
10kΩ unbalanced
Input sensitivity 0dB / 0.775V
Subsonic filter 30Hz - 12dB/oct
Max power consumption 260 VA
Weight 16 kg - 35.2 Kg
Shipping weight and volume 19.2 kg - 0.133 cbm
System type 2-way vented wedge
enclosure
Nominal impedance 8Ω
Continuous power rating 170 W (AES standard)
Peak power rating 340 W
Frequency response
65Hz - 20KHz @ ± 6dB
Sensitivity 97dB @ 1W/1m
Rated Maximum SPL 122dB
Low frequency device 12” woofer
High frequency device 1” compression driver
Coverage dispersion angle 90°H x 60°V
Crossover frequency 3500Hz
Connectors 2 x SPK4MP linked
Enclosure High grade low-reso-
nance impact wood
Dimensions (WxHxD) 39 x 46 x 32.5 cm
Weight 13 kg – 28.7 lbs
Shipping weight and volume 15.8 kg - 0.133 cbm
System type 2-way vented wedge
enclosure
Nominal impedance 8Ω
Continuous power rating 270W (AES standard)
Peak power rating 540 W
Fr
equency response
55Hz - 20KHz @
± 6dB
Sen
sitivity 98dB @ 1W/1m
Rated Maximum SPL 125dB
Low frequency device 15” woofer
High frequency device 1” compression driver
Coverage dispersion angle 90°H x 60°V
Crossover frequency 3500Hz
Connectors 2 x SPK4MP linked
Enclosure High grade low-reso-
nance impact wood
Dim
ensions (WxHxD) 46 x 49 x 38 cm
W
eight 18.5 kg - 40.8 lbs
Shipping weight and volume 20.3 kg - 0.188 cbm
SMT12MP - SMTV12MP SMT12MA - SMTV12MA
SMT15MP - SMTV15MP
DATI TECNICI
TECHNICAL DATA
SMART plus / SMART V plus
Powered version
Max power
320W IHF
Continuous power
250W EIA (RMS)
Input impedance 20kΩ balanced
10kΩ unbalanced
Input sensitivity 0dB / 0.775V
Subsonic filter 30Hz - 12dB/oct
Max power consumption 510 VA
Weight 23 kg - 50.7
Shipping weight and volume 26 kg - 0.188 cbm
SMT15MA - SMTV15MA
System type Vented enclosure
subwoofer
Nominal impedance 4Ω / 8Ω
Continuous power rating 170W (AES standard)
Peak power rating 340W
Frequency response
55Hz - 160Hz @ ± 6dB
Sensitivity 97dB @ 1W/1m
Rated Maximum SPL 122dB
Low frequen
cy d
evice 12” woofer
Crossover frequency 160Hz
12dB/oct low-pass
6dB/oct high-pass
Connectors 2 x SPK4MP linked
Enclosure High grade low-reso-
nance impact wood
Dimensions (WxHxD) 39.5 x 46 x 45.5 cm
Weight 18 kg - 39.7 lbs
Shipping wei
gh
t and volume 21 kg - 0.085 cbm
SMT12SP4/P8 - SMTV12SP4/P8
Powered version
Max power
320W IHF
Continuous power
250W EIA (RMS)
Input impedance 20kΩ balanced
10kΩ unbalanced
Input sensitivity 0dB / 0.775V
Subsonic filter 30Hz - 12dB/oct
Max power consumption 510 VA
Weight 23.6 kg - 63 lbs
Shipping weight and volume 26.6 kg - 0.085 cbm
SMT12SA - SMTV12SA
System type
V
ented enclosure
subwoo
fer
N
ominal impedance 4Ω / 8Ω
Con
tinuous power rating 300W (AES standard)
P
eak power rating 600W
Fr
equency response
40Hz - 160Hz @
± 6dB
Sen
sitivity 98dB @ 1W/1m
Rated M
aximum SPL 125dB
Low fr
equency device 15” woofer
Cr
ossover fr
equency 160Hz
12dB/oct low-pass
6dB/oct hi
gh-pass
Conn
ectors 2 x SPK4MP linked
En
closure High grade low-reso-
n
ance impact wood
Dim
ensions (WxHxD) 46.5 x 55 x 38 cm
W
eight 23 kg - 50.7 lbs
Shippin
g weight and volume 26 kg - 0.177 cbm
SMT15SP4/P8 - SMTV15SP4/P8
Powered version
Max power
320W IHF
Continuous power
250W EIA (RMS)
Input impedance 20kΩ balanced
10kΩ unbalanced
Input sensitivity 0dB / 0.775V
Subsonic filter 30Hz - 12dB/oct
Max power consumption 510 VA
Weight 28.6 kg - 63 lbs
Shipping weight and volume 31.2 kg - 0.177 cbm
SMT15SA - SMTV15SA
System type Vented enclosure
subwoofer
Nominal impedance 4Ω / 8Ω
Continuous power rating 400W (AES standard)
Peak power rating 800W
Frequency response
40Hz - 160Hz @ ± 6dB
Sensitivity 98dB @ 1W/1m
Rated Maximum SPL 127dB
Low frequency device 18” woofer
Crossover frequency 160Hz
12dB/oct low-pass
6dB/oct high-pass
Connectors 2 x SPK4MP linked
Enclosure High grade low-reso-
nance impact wood
Dimensions (WxHxD) 54.5 x 64 x 48 cm
Weight 28 kg - 61.7 lbs
Shipping weight and volume 32 kg - 0.270 cbm
SMT18SP4/P8 - SMTV18SP4/P8
Powered version
Max power
320W IHF
Continuous power
250W EIA (RMS)
Input impedance 20kΩ balanced
10kΩ unbalanced
Input sensitivity 0dB / 0.775V
Subsonic filter 30Hz - 12dB/oct
Max power consumption 510 VA
Weight 33.6 kg - 73.9 lbs
Shipping weight and volume 37.6 kg - 0.270 cbm
SMT18SA - SMTV18SA
