9
10.Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place. The large allen wrench is used to adjust the
walking belt (see page 16). To protect the floor or carpet, place a mat under the treadmill.
8. See step 3. Firmly tighten the 1” Bolts (63) and the 2”
Bolts (114).
Lower the Handrails (not shown) to the floor. Make sure
that the Frame (86) is centered between the
Handrails. Firmly tighten the 3” Bolts (61).
Raise the
Handrails to the vertical position.
69
86
61
61
8
9. Attach the Weight Rack (107) to the Uprights (73, 108) as
shown with four 3/4” Screws (2). Set the hand weights (not
shown) on the Weight Rack, with the lightest weights in the
center.
9
73
108
107
2
2
To Next Page
