PART LIST—Model No. PFTL59007.0 R
0707A
Key No. Qty. Description Key No. Qty. Description
1
2 Foot Rail Decal
2 6 1/2" Screw
3 31 Screw
4 1 Reset/Off Circuit Breaker
5 8 Foot Rail Screw
6 4 Isolator
7 6 Hood Screw/Tie Screw
8 2 Upright Round Endcap
9 2 Platform Bolt, Back
10 2 Platform Bolt, Front
11 4 Belt Guide Screw
12 2 Belt Guide
13 1 Power Cord Grommet
14
2 Front Endcap Screw
15 2 Frame Pivot Bolt
16 1 Left Foot Rail
17 1 Right Foot Rail
18 1 3/8" x 1 3/4" Bolt
19 1 3/8" Flat Washer
20 2 Handrail
21 1 Latch Pin
22 1 1 1/4" Plastic Washer
23 1 Idler Arm
24 2 Motor Bolt
25 1 5/16" x 1 1/2" Bolt
26 1 Motor Belt
27 1 Drive Motor
28 2 Frame Spacer
29 1 Incline Motor Bolt, Upper
30 1 Idler Arm Spring
31 2 Lift Frame Bolt
32
7
Lock Nut
33 9 Ground Screw
34 1 Console
35
2
Extension Leg Base Pad
36 1 Power Cord
37 1 Transformer
38
1 Controller
39 1 Electronic Bracket
40 1 Filter Wire
41 1 Hood
42
1
Front Roller Bushing
43 1 Lift Frame
44 2 Front Endcap
45 1 Front Roller Bolt
46 1 Magnet
47 1 Front Roller/Pulley
48 1 Walking Belt
49 1 Walking Platform
50 1 Incline Motor/Controller Wire
5
1 1 Rear Roller
52 1 Left Rear Endcap
53 2 Rear Roller Bolt
54 1 Right Rear Endcap
55 1 Hex Key
56 1 Incline Stop Bracket
57 1 Base Ground Wire
58 1 Frame
59 1 Belly Pan
60 2 Center Isolator
61 1 Reed Switch Clip
62 2 Handrail Endcap
63 1 Reed Switch
64
4 Handrail Bolt
65 2 2 1/2" Extension Leg Bolt
66 2 Rear Roller Washer
67 2 Extension Leg Nut
68 2 Caution Decal
69 1 Warning Decal
70 2 Platform Nut
71 10 Cable Tie
72 3 Belly Pan Screw
73 1 Latch Housing
74 1 5/16" Flat Washer
75 2 Releasable Tie
76 1 Access Door
77 1 Wire Harness
78 2 Extension Leg Endcap
79 1 Key/Clip
80 2 Front Wheel
81 2 Wheel Pin
82
2
Base Pad
83 4 1" Tek Screw
84 1 Upright
85
1
Console Base
86 1 Incline Motor Bolt, Lower
87 1 Idler Pulley
88
1 Incline Motor
89 2 Extension Leg
90 2 Rear Roller Bracket
91 1 Front Roller Nut
92
2
2 1/4" Extension Leg Bolt
93 1 Optic Disk
94 1 Photo Switch Nut
95 2 Small Star Washer
96 1 Photo Switch
97 1 Photo Switch Bolt
98 2 Dumbbell
99 1 Latch Plate
100 5 Wire Tie
To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual.
