ProForm 525 User Manual

PART LIST—Model No. PETL17021 R0702A
Key No. Qty. Description
1 2 Handrail
2
1 Key/Clip
3 1 Upright Grommet
4 1 Battery Cover
5 2 Foot Rail
6 1 Receptacle
7 4 Isolator Spacer
8 1 Speed Potentiometer
9 1 Speed Control Knob
10* 1 Console Assembly
11 1 Upright
12 1 Motor Belt
13 14 3/4” Screw
14 1 Storage Latch
15 1 Bumper
16 9 8” Cable Tie
17 1 Motor Swivel Nut
18 1 Pulley/Flywheel/Fan
19 1 Motor
20* 1 Motor/Pulley/Flywheel/Fan
21 1 Wire Harness
22 2 Long Hood Screw
23 1 Motor Hood
24 1 Hood Shield
25 4 Belt Guide Screw
26 1 Controller
27 1 Motor Swivel Bolt
28 1 Motor Tension Nut
29 1 Motor Tension Star Washer
30 1 Motor Tension Washer
31 1 Motor Tension Bolt
32 1 Filter
33 21 Belly Pan Screw/Clip Screw
34 2 Extension Leg
35
2 Motor Pivot Bushing
36
2
Wheel Bolt
37 2 Wheel
38 6 Wheel Nut/Lift Nut
39
9
Washer
40 4 Base Pad
41 1 Motor Pivot Sleeve
42
1 Latch Catch
43 1 Reed Switch Clip
44 1 Reed Switch
45 1 Magnet
46
1
Console Base
47 2 Frame Pivot Spacer
48 4 Platform Screw
49 4 Isolator
50 1 Front Roller/Pulley
51 1 Front Roller Adj. Bolt
Key No. Qty. Description
52 2 Incline Leg Cap
53
2 Extension Leg Screw
54 1 Power Cord Set
55 4 Plastic Washer
56 1 Circuit Breaker
57 2 Frame Pivot Washer
58 2 Frame Pivot Bolt
59 1 Electronic Bracket
60 1 Motor Belly Pan
61 2 1” Grommet
62 2 Rear Platform Screw
63 2 Support Washer
64 1 Choke
65 2 Belt Guide
66 2 Incline Pin
67 1 Walking Belt
68 1 Walking Platform
69* 2 Base Leg Assembly
70 16 Electronics Screw
71 1 Grounding Washer
72 3 Wire Tie Holder
73 8 Isolator Screw
74 1 Allen Wrench
75 1 Frame
76 1 Left Front Endcap
77 1 Grounding Bolt
78 1 Right Front Endcap
79 1 Grounding Nut
80 1 Grounding Wire
81 4 Latch Screw/Handrail Screw
82 2 Incline Leg
83 2 Rear Roller Adj. Bolt
84 1 Rear Endcap
85 1 Latch Decal
86
1 Rear Roller
87
2
Rubber Ring
88 2 Handrail Bolt
89 1 Grounding Screw
90
1
Belt Guard
91 1 Ferrite Box
92 1 Filter WIre
#
1 4” White Wire, 2F
# 1 8” White Wire, 2F
# 1 4” Green/Yellow Wire
# 1 4” Black Wire, 2F
#
1
6” Black Wire, 2R
# 2 Insert Nut
# 1 User’s Manual
* Includes all parts shown in the box
# These parts are not illustrated

ProForm 525 Specifications

General

Motor (Alternative)	2.5 CHP
Speed Range	0-10 MPH
Incline Range	0-10%
Weight	203 Lbs
Incline	0 – 10% Digital Incline Control
Speed	0-10 mph
Display (Alternative)	Backlit LCD
Motor	2.5 CHP Mach Z™ Motor
