6
4. Slide the upper end of one of the Handrails (1) onto the
post on one of the Uprights (11). Push the Handrail as far
forward as possible. Tighten a Handrail Screw (81) into
the Handrail. Next, align the lower end of the Handrail
with the hole in the Upright. Tighten a Handrail Bolt (88)
with a Washer (39) into the Handrail and the Upright.
Attach the other Handrail (1) as described above.
5. Attach the Storage Latch (14) to the left Upright (11) with
two Latch Screws (81). Be careful not to overtighten
the Latch Screws.
6. Make sure that all parts are properly tightened before you use the treadmill. Keep the included allen
wrench in a secure place. The allen wrench is used to adjust the walking belt (see page 13). To protect the
floor or carpet, place a mat under the treadmill.
11
81
11
81
88
39
39
88
1
1
4
81
14
11
5
3. Slide a Rubber Ring (87) onto the handrail post on each
Upright (11).
87
87
Post
Post
11
11
3
To Next Page
