9
7. Insert the upper end of the Left Handrail (71) into
the tube on the Console Frame (87). Hold the
lower end against the Left Upright (75).
Attach the Left Handrail (71) with two 1/4" x
1 3/4" Screws (10), two 1/4" Star Washers (11),
and two 1/4" x 5/8" Screws (9) as shown; do not
tighten the Screws yet.
Attach the Right Handrail (not shown) as
described above.
9
11
7
75
10
71
6. Attach the Console Frame (87) to the Left and
Right Uprights (75, 76) with two 5/16" x 3 1/4"
Screws (7) and two 5/16" Star Washers (8); do
not fully tighten the Screws yet.
87
76
75
8
7
8
7
6
87
To Next Page
