5. With the help of a second person, carefully tip
t
he treadmill onto its right side. Partially fold the
Frame (53) so the treadmill is more stable;
do
not fully fold the Frame yet.
R
emove and discard the two indicated bolts (A)
and the shipping bracket (B).
Attach a Base Pad (79) to the Base (80) in the
location shown with a Base Pad Spacer (25)
and an 1" Tek Screw (56). Then, attach another
Base Pad (79) with only a 1" Tek Screw (56).
Remove the 3/8" Nut (8), the 3/8" x 2" Bolt (4),
and the shipping bracket (C) from the Base (80).
Attach a Wheel (81) with the Bolt and the Nut
that you just removed. Do not overtighten the
Nut; the Wheel must turn freely. Discard the
shipping bracket.
7. Have a second person hold the console assem-
bly near the Right Upright (72). Remove the wire
tie from the Upright Wire (78).
Connect the Upright Wire (78) to the console
wire. The connectors should slide together
easily and snap into place.
If they do not, turn
one connector and try again. IF THE CON-
NECTORS ARE NOT CONNECTED PROP
-
ERLY, THE CONSOLE MAY BE DAMAGED
WHEN THE POWER IS TURNED ON. Then, in
-
sert the connectors into the Right Upright (72).
Set the console assembly on the Right Upright
(72) and the Left Upright (not shown). Attach the
console assembly with four 5/16" x 1" Bolts (5)
and four 5/16" Star Washers (7);
start all four
Bolts and then tighten them.
5
72
7
78
Console
Assembly
Console
Wire
Wire Tie
7
5
7
78
5
80
81
53
4
8
C
79
56
79
25
56
B
A
6. With the help of a second person, hold a Bolt
Spacer (3) inside the lower end of the Left
Upright (71). Insert a 3/8" x 2" Bolt (6) with a
3/8" Star Washer (9) into the Left Upright and
the Bolt Spacer. Repeat this step with a second
Bolt Spacer (3), 3/8" x 2" Bolt (6), and 3/8" Star
Washer (9).
Orient the Left Upright (71) and the Left Upright
Spacer (73) as shown. Hold the Left Upright
Spacer and the Left Upright against the Base
(80). Finger tighten the 3/8" x 2" Bolts (6);
do
not fully tighten the Bolts yet.
Press a Base Endcap (75) into the Base (80).
With the help of a second person, tip the tread-
mill so that the Base (80) is flat on the floor.
73
71
6
80
3
3
75
9
6
