6
2. Attach a Wheel (50) to the front of the Frame (1)
with an M10 x 35mm Shoulder Screw (63).
Repeat this step to attach the other
Wheel (50).
2
1.
While another person lifts the rear of the Frame
(1), attach a Frame Cover (48) to the Frame
with two M4 x 16mm Screws (84).
Repeat this step to attach the other
Frame Cover (48).
48
1
1
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
84
63
50
1
63
50
84
48
To Next Page
