14
5
5
121
Battery
Cover
Battery
Cover
17
17. See the upper drawing. Plug the Power
Adapter (121) into the receptacle inside the
battery compartment on the Console (5).
To plug the Power Adapter (121) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 15.
See the lower drawing. The Console (5)
can also be operated with four D batteries
(not included); alkaline batteries are recom-
mended. Do not use old and new batteries
together or alkaline, standard, and recharge-
able batteries together.
Remove the screws, remove the battery
covers from the back of the Console (5),
and insert batteries into the battery compart-
ments. Make sure to orient the batteries
as shown by the diagrams inside the
battery compartments. Then, reattach the
battery covers.
Receptacle
18. Make sure that all parts of the elliptical are properly tightened. Note: Extra parts may be included. To
protect the floor or carpet from damage, place a mat under the elliptical.
Receptacle
To Next Page
