10
9. Attach the Left Handrail (107) and the Right
Handrail (104) with six 5/16" x 1" Bolts (6) and
four 5/16" Star Washers (13) as shown. Do not
f
ully tighten the Bolts yet.
S
lide the Handrail Caps (105) away from the
Uprights (75, 80). Attach the lower end of each
Handrail (104, 107) to the Uprights with a #10 x
3/4" Screw (5).
Orient the Handrail Caps (105) as shown.
Secure a Handrail Cap to each Handrail (104,
107) with a #8 x 1/2" Screw (2).
7
5
6
13
6
2
2
5
5
6
6
13
80
9
10. Set the console assembly face down on a soft
surface to avoid scratching the console assem-
bly.
Remove the two #8 x 1/2" Screws (2) from the
Crossbar (106), and then remove the Crossbar.
Save the Crossbar and the two Screws for
steps 11 and 14.
Console
Assembly
2
2
106
10
105
104
107
105
