13
2. Using a flathead screwdriver or needle nose pliers, remove clip from
strain relief portion of the cord.
3. Using wire cutters, cut black (or brown) wire and white (or blue) wire
near the connectors.
4. Pull cord strain relief out of endbell. Cut green ground wire near the
cord strain relief.
5. Insert metal strain relief connector (not included) into the endbell
hole and tighten the nut securely.
6. Strip the green, black, and white insulation from last ½” of each wire.
2
6B
3
6C
4
6D
5
6E
6
6F
