READ CAREFULLY AND COMPLETELY BEFORE STARTING
NOTE: As the mounting assembly is properly assembled at the factory, please pay close attention
to the order of the mounting system parts.
Attachment included with PSD-90
and PSD-125 models only
(see page 10 for installation)
LOWER MOUNT RING*
DISPOSER
DISHWASHER INLET
CUSHION RING
MOUNT TAB
INSTALLATION OF MOUNTING ASSEMBLY
A Stopper 1
B Removable Splash Guard 1
C Sink Flange 1
D Fiber Gasket 1
E Support Flange 1
F Upper Mount Ring 1
G Mount Screws 1
H Retainer Ring 1
I Cushion Rign 1
J Lower Mount Ring 1
K Silver Guard 1
I
PART DESCRIPTION QUANTITY
J
FEGH
K
To Next Page
