8
6. Hold the three parts in place while attaching the Retainer Ring (2H)
by pulling it apart and having it snap within the groove of the sink
flange (2I).
F1
F2
G1
7. Tighten the three Mount Screws evenly and firmly against the
Support Flange (2J). Do not over tighten.
8. Trim off any excess plumber’s putty in the sink with a plastic knife or something similar that
will not damage your sink.
CONNECTION
If you are utilizing a dishwasher, complete the following procedure.
Using a blunt instrument (steel punch or wooden dowel), knock out entire
plug. Do not use a screwdriver or sharp instrument. (When knockout plug
falls into disposer, you may remove it or grind it up when the disposer is
used. This will not damage the disposer in any way, but it may take some
time to grind).
Knock
Out Plug
Wood or Metal
Dowel
2H
2I
2J
