SPECIFICATIONS
Operating Conditions
Alternator Input Voltage 9-32Vdc
Maximum Solar Input Voltage 23Vdc
Maximum Input Current 40A
Input Current (No Load) 20mA
Back Drain on Auxiliary Battery 9.5 – 10.5mA
External LED Output – Constant Current 4 mA
Output Current Input 9–11Vdc: 20A
Input 11V-32dc: 25A
Input Fuse Rating 50A (Not supplied)
Output Fuse Rating 50A (Not supplied)
Maximum Output Power 385W
Solar Input Turn On Voltage 9V
Size 149 x 122 x 42 mm
Weight 800g
Operating Temperature (Derated from 55
o
C) -10 to +80
o
C (Ambient Temperature)
Charge Control
Charge Type 3 Stage
Bulk *20A at 9-11Vdc, 25A at 11-32Vdc *Constant Current up to:
GEL AGM WET CALCIUM
14.1V 14.4V 14.7V 15.4V
Absorption Constant Voltage until current drop to 3.8A
GEL AGM WET CALCIUM
14.1V 14.4V 14.7V 15.4V
Float Keep Constant Voltage at 13.7V
Equalisation 3.8A Constant Current Charge up to 16V
(Calcium mode only) then hold for 1 hour (5 hour timeout)
Battery Range
Battery Capacity 75-300Ah
Type of Batteries Supported GEL, AGM, WET & CALCIUM
Operating Mode
12V Vehicle 24V Vehicle
VSR Mode – Default (Ignition Override Turn on Turn off Turn on Turn off
Not Connected) 13.4-20V <12.8V 26.8-32V < 25.6V
Low Voltage Mode – Ignition Override cable Turn on Turn off Turn on Turn off
connected to ignition switch (ignition on) 12.2-20V <11.9V 24.4-32V <24V
Standards
EMC C-Tick, AS/NZS CISPR11:2011 Class B
IP Rating IP67
