STEP 5 – SET CHARGE RATE
The charge rate should be set according to the size of the battery. See the recommended
charge rates for various battery sizes in the table below.
(Not all ouputs are available on all models)
a. Press the CHARGE RATE button. The LCD screen will flash the present setting.
b. Press the CHARGE RATE button repeatedly until desired setting is displayed.
c. Wait for the LCD screen to stop flashing.
Note: Failure to wait for the screen to stop flashing will cause the charge rate to default
to previous setting.
ADJUSTABLE CHARGE RATES: 12 VOLT BATTERIES
CHARGE RATE BATTERY SIZE (12V)
Deep Cycle (AH) Automotive (CCA) Marine (MCA) Time (Hours) Lithium (AH) Time (Hours)
2 Amp 14–40 80–240 110–330 7–24 4–20 2–10
6 Amp 40–120 240–720 330–1000 7–24 12–60 2–10
8 Amp 40–160 240–1000 330–1300 7–24 16–80 2–10
12 Amp 80–240 480–1440 660–2000 7–24 24–120 2–10
16 Amp 110–320 660–1900 930–2700 7–24 32–160 2–10
25 Amp 170–500 1000–3000 1400–4200 7–24 50–250 2–10
35 Amp 240–700 1440–4200 2000–5800 7–24 70–350 2–10
50 Amp 350–1000 2100–6000 2900–8300 7–24 100–500 2–10
ADJUSTABLE CHARGE RATES: 24 VOLT BATTERIES (IC8-24)
CHARGE RATE BATTERY SIZE (24V)
Deep Cycle (AH) Automotive (CCA) Marine (MCA) Time (Hours) Lithium (AH) Time (Hours)
2 Amp 14–40 80–240 110–330 7–24 4–20 2–10
4 Amp 30–80 180–480 250–650 7–24 8–40 2–10
6 Amp 40–120 240–720 350–1000 7–24 12–60 2–10
8 Amp 60–160 360–1000 500–1300 7–24 16–80 2–10
STEP 6 – SET BATTERY CHEMISTRY TYPE
Battery Chemistry should be selected by the type of battery being charged (refer to the
battery manufacturer’s specifications for battery type). Refer to page 5 for a detailed
explanation.
For example, if you are charging an AGM battery, then AGM mode will need to be
selected. This can be done by the following procedure:
a. Press the BATTERY TYPE button. The LCD screen will flash the present setting.
b. Press the BATTERY TYPE button repeatedly until desired setting is displayed.
c. Wait for the LCD screen to stop flashing.
Note: Failure to wait for the screen to stop flashing will cause the charge rate to default
to previous setting.
To Next Page
