ProLights WIFIBox - Manual Channel; Auto Channel; Input Mode; Information

WiFiBoX
6
MENU
1 Manual Channel
ð
<CH01>
...
<CH16>
2 Auto Channel
ð
<CHxx>
3 Input Mode
ð
<Wi>
<DMX>
4 Information
ð
WIFI SSID
ð
<WIFI-TEST>
WIFI Channel
ð
<11>
Reset WIFI
ð
<Reset>
3.3 MENU STRUCTURE
3.4 MANUAL CHANNEL
To manually select the channel for communication data refer to the following steps:
• Press the button MENU so many times until shows Manual Channel.
• Press the button ENTER to conrm.
• Using UP/DOWN button, select one of the value CH01 - CH16.
• Press the button ENTER save the setting.
3.5 AUTO CHANNEL
To automatically select the channel for communication data refer to the following steps:
• Press the button MENU so many times until shows Auto Channel.
• Press the button ENTER save the setting.
3.6 INPUT MODE
To select the data input mode refer to the following steps:
• Press the button MENU so many times until shows Input Mode.
• Press the button ENTER to conrm.
• Using UP/DOWN button, select one of the programs WIFI - DMX.
• Press the button ENTER save the setting.
3.7 INFORMATION
To show the device information refer to the following steps:
• Press the button MENU so many times until shows Information.
• Press the button ENTER to conrm.
• Using UP/DOWN button to scroll through the programs WIFI SSID - WIFI Channel - Reset WIFI.
• Read the desired information or wait WIFI signal’s reset.
3.8 TRANSMITTER MODE WITH DMX INPUT
• Connect the WIFIBOX transmitter to a DMX controller so that it can transmit the signal to the connected
equipment.
• Turn on all units.
