31
INSTALLATIONINSTRUCTIONS
Inthebenchtop
A B C D E F
268
mm
490
mm
50mm
mini
50mm
mini
50mm
mini
50mm
mini
Onthebenchtop
A B
50mm
mini
50mm
mini
Built‐inscheme
C/D/E/F: minimum distance between the cutout of the hob and the
nearest surface
