3 Function blocks for gamma/L and Sigmas
3.1 Introductory information
In the sample project there are 2 variants of function blocks:
1 -
FB110 for basic functionality
2 - FB111 for complete functionality
1 FB110 for basic functionality contains the functions:
n Start/Stop
n Setpoint 0-100%
n Warning/fault message (group bit)
n Simple PROFIBUS
®
monitoring
2 FB111 for complete functionality contains the functions:
n Start/Stop
n Selection of setpoint specification/lot
n Batch handling
n Contact activation with specification of a factor
n Setpoint 0-100%
n Stroke counter
n Quantity counter
n Concentration output (option)
n Warning/fault message (group bit)
n Detail specification of the warning
n Detail specification of the fault message
n Simple PROFIBUS
®
monitoring
In the hardware address "I_ADR_Name" and "O_ADR_Name” mean ...
I_ Input
O_ Output
ADR_ Address
Name Name
.
In the interface names “abName” means ...
a (variants)
i Input
o Output
stat Statistical range of the function
block
b (variants)
Variant Type Value range
x Bool false, true
y Byte 0 ... 255 16#00... 16#FF
i Int 0 ... 65535 -32768 ... 32767
Functions of the function blocks
Explanation of the names in the standard
function blocks
Function blocks for gamma/L and Sigmas
28
