ProMinent gamma/l Installation And Configuration Manual

Interfaces Type Description
ixStart_Stop Bool If a 1 is applied on this input and if there is no fault, the
pump will be activated.
If the pump does not run or is not at a standstill the fol‐
lowing causes are possible:
n PROFIBUS
®
is faulty
n Pump is not in PROFIBUS
®
mode
n PROFIBUS
®
address is not correct
n Configuration is not correct
n Pump is manually set to stop
n Setpoint is on 0% (irSetpoint_0_100)
n ixFault_Lock = 1 and oxError = 1 or oxProfibus = 1
n Use Profibus Workaround
Adapt iiCycle_Error
ixReset Bool Resets the bit messages oxWarning, oxError and oxEr‐
rorProfibus. Resets the pump (positive flank sent).
ixFault_Lock Bool If 0, then the pump does not include a locking mechanism
for stored faults.
Logical link:
Start pump = ixStart_Stop
i.e. because the faults oxError and oxErrorProfibus
require acknowledgment, the pump automatically starts
up again if there is a fault on both sides.
If 1, then the pump does not include a locking mechanism
via fault messages oxError or oxErrorProfibus.
Logical link:
Start pump = ixStart_Stop & oxError = 0 & oxErrorPro‐
fibus = 0
i.e because the faults oxError and oxErrorProfibus
require acknowledgment, the pump does not automati‐
cally start up again if there is a fault on both sides.
irSetpoint_0_100 Real Entry of the setpoint of the metering pump in %.
The formula of the calculation is:
Set frequency = MaxFrequency * irSetpoint / 100
Through the real number the speed on the stroke can be
precisely selected, because the entry of 49.99%, for
example, is possible.
Likewise a direct connection of the integrated S7 con‐
troller is possible. For this the output parameter LMN
must be connected on this input.
Interfaces of the function block
Function blocks for gamma/L and Sigmas
32
