ProMinent gamma/l - Programmable Function Settings

Address Type Slot
O_Adr_Control Int 1
O_Adr_Reset Int 5
O_Adr_Operation_Mode Int 7
O_Adr_Frequency Int 9
The input addresses or output addresses of gamma/ L or Sigma for the
CPU can be read out in the Hardware Configurator under gamma/ L or
Sigma for the appropriate slots:
Fig. 29
A more detailed explanation of the functions that are
assigned to the slots is provided in the “Supplemental
manual for gamma/ L and Sigma versions with PROFIBUS
®
”.
Relationship: Slots - address ranges of the
function block
Function blocks for gamma/L and Sigmas
