SECTION 7—SEAT
Part No. 1139640 39 Pronto® M61™with SureStep®
SECTION 7—SEAT
 WARNING
After any adjustments, repair or service and before use, make sure that all attaching
hardware is tightened securely - otherwise injury or damage may result.
Before performing any maintenance, adjustment or service verify that On/Off
switch on the joystick is in the Off position.
Adjusting the Back Angle
NOTE: For this procedure, refer to FIGURE 7.1.
1. Lift up on the release handle and adjust seat to desired angle.
2. Let go of the release handle to lock the back in position.
FIGURE 7.1 Adjusting the Back Angle
Adjusting the Headrest
NOTE: For this procedure, refer to FIGURE 7.2.
1. To raise the headrest, lift the headrest up to the desired position.
2. To lower the headrest, push the release tab towards the front of the wheelchair. Lower
the headrest to the desired position.
FIGURE 7.2 Adjusting the Headrest
Release Handle
Headrest
Release Tab
Headrest
Tube
