SECTION 7—SEAT
Pronto® M61™with SureStep® 46 Part No. 1139640
FIGURE 7.7 Installing Seat Angle Bracket for 5° Tilt
Seat Base
Seat Adapter Plate
Seat Angle
Bracket
DETAIL “A”
DETAIL “B”
Flanges
Seat Angle
Bracket
Washer
Mounting
Screws
Mounting
Screws
Washers
Locknuts
NOTE: Optional height adjustment spacers not
shown. Only one set of spacers can be installed
when the seat angle bracket is installed.
Seat Base
Seat Assembly
OTE: Seat assembly not shown for clarity.
NOTE: Arrows show mounting holes.
Seat Angle
Bracket
Flange
DETAIL “C”
Front of Seat
Rear of Seat
Flange
To Next Page
