Pronto M61 - Front Rigging Bracket Mounting Options

SECTION 9—FRONT RIGGINGS
Part No. 1139640 53 Pronto® M61™with SureStep®
FIGURE 9.1 Adjusting Front Rigging Bracket Position
Seat Base
Front Rigging
Bracket
Hanger
Hanger Mounting
Screws
Mounting Screw
Hanger
DETAIL “B” - FRONT RIGGING BRACKET MOUNTING HOLES (BOTTOM VIEW)
Front Rigging Bracket
Most Extended
DETAIL “A”
NOTE: The front rigging bracket mounting holes would be the same for all seat depths. Refer
to Adjusting Seat Depth
on page 41 to change the seat depth.
Front Rigging Bracket
Half Extended
Front Rigging Bracket
Least Extended
Bracket
Tube
Washer
Mounting
Screw
Washers
NOTE: Arrows show
mounting holes.
Seat Back
Brackets
Seat Back
Brackets
Seat Back
Brackets
Front
Rigging
Bracket
Front
Rigging
Bracket
Front
Rigging
Bracket
Front of Seat
Rear of Seat
