PLM-8000 Operation Manual
12
Press this button in order to change CYL (+) from.
Button for clearing the value of the measured data to ‘0’
Button for print out the measured value
To enter the UV or Blue measurement icon screen
To enter the UV/Blue measurement graph screen
Adjust the current transmission to 100%(UV and BLUE)
4.4.3 UV/BLUE Display
1. Measured data
3. Current Protection Ratio
4. Current Protection Height
2. Current Transmission Ratio
