User Manual
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany
1.2.2.1 Floor capacity
NOTE
system is primarily made of metal pieces. This has a main role in
the weight of the device.
The radiographic system PRS 500 E has a weight of 850kg (incl. Generator).
Every technician is obliged to check the ground load. Also double bottoms and
hollow floors have to be taken into account.
1.3 Product specific characteristics
1.3.1 Variable height radiographic table
• Variable table height
• PROGNOST E Standard (58.9cm – 87.6 cm)
• Floating table top
• Table top colour – white
• Motor activated table top brake for effortless patient positioning
• A low (optimized) distance between the table top surface and the film (detector) surface
• Large adjustment range of the table top for position of the patient
• Reliable construction
• Lateral rails of the table top prepared to accept a number of table accessories
• Prepared for the installation of a Bucky with anti-scatter grid and 3-field measuring chamber
intended for the use with automatic exposure control
• Useable for variable cassette/detector sizes. Formats from 13 cm x 18 cm (5” x 7”) to 43 cm x 43
cm (17” x 17”), depending on analog or digital use
1.3.2 Floor railed X-ray system tube support
• Ceiling-free column stand intended for use within rooms with a ceiling height of at least 2.3
meters
• Wide range of application
• Small wall distance allows good space utilization
• Control elements within the command arm well placed and easy to activate
• Reproducible positioning of the X-ray tube assembly (positions resulting from rotation around
the axis of the carrying arm) through angle indicator
• Vertical range of travel of the focus height from 29.4 cm up to 188.2 cm during horizontal
beam projection
• Electromagnetic brakes for the longitudinal movement of the column stand, the vertical
movements of the carrying arm as well as the rotational movements of the X-ray tube
assembly around the axis of the carrying arm +/-180° with integrated latching every 90°
• Integrated safety connector for automatically centering the X-ray tube assembly and the Bucky
in the longitudinal direction
1.3.3 Vertical X-ray system image receptor stand
• Space saving with minimal footprint
• Wall-floor mounting of floor mounting
• cassette loading from the right or left side (specified at installation)
• Useable for variable cassette/detector sizes. Formats from 13 cm x 18 cm (5” x 7”) to 43 cm x 43
cm (17” x 17”), depending on analog or digital use
1.4 Intended use
The general-purpose diagnostic radiographic systems of the PRS 500-series are intended for various
routine applications in planar X-ray imaging in human medicine.
They are stationary systems that can be used both for analogue and digital imaging.
