3.2.2 Operating unit PROGNOST SH, TOUCH
1 Touch display of X-ray tube assembly
2 Brake release horizontal movement of X-ray system tube support, floor stand
3 Brake release movement of X-ray tube assembly around the horizontal support arm axis
4 Brake release vertical movement of X-ray tube arm and horizontal movement of X-ray
system tube support, floor stand
5 Brake release vertical movement of X-ray tube arm and horizontal movement of X-ray
system tube support, floor stand
6 Brake release movement of X-ray tube assembly around the horizontal support arm axis
7 Brake release vertical movement of X-ray tube arm
Detailed information please find in the accompanying User Manual PROGNOST SH.
2
3
4
7
6
5
1
