3 Control elements and device displays
3.1 Control elements and device displays PROGNOST E
Detailed information please find in the accompanying User Manual of the PROGNOST E.
3.2 Control elements and device displays PROGNOST SH
3.2.1 Operating unit PROGNOST SH, Standard
1 Angle indicator for adjustment of X-ray assembly
2 Brake release horizontal movement of X-ray system tube support, floor stand
3 Brake release movement of X-ray tube assembly around the horizontal support arm axis
4 Brake release vertical movement of X-ray tube arm and horizontal movement of X-ray
system tube support, floor stand
5 Brake release vertical movement of X-ray tube arm and horizontal movement of X-ray
system tube support, floor stand
6 Brake release movement of X-ray tube assembly around the horizontal support arm axis
7 Brake release vertical movement of X-ray tube arm
8
9
10
11
12
13
14
15
16
17
18
19
20
21
2
3
4
7
6
5
1
