6 Electrical data
NOTE
The
radiographic
system is in need
of the
following power supply (see table „Power
supply Generator).
Type generator
PROVARIO
HF 50
PROVARIO
HF 60
PROVARIO
HF 80
Venus 50R, 3
phase
Venus 50R, 1
phase
Output Power
50kW
65kW
80kW
50kW
50kW
Power supply
voltage
400V AC
380V AC/400V
AC
220V AC
Phase
3PH
-
N
-
PE
3PH
-
N
-
PE
1phase
Power frequency
50/60 Hz
50/60Hz
50/60Hz
Electrical
resistance per
phase
0,3Ω 0,2Ω 0,12Ω 0,15 Ω/0,17 Ω 0,5Ω
Fuse
50A
63A
16A
List (Power supply generator)
WARNING!
To lower the risk of an electrical shock, the device can only be run on a power
supply with a protective conductor.
6.1 Electromagnetic Compatibility (EMC) after EN 60601-1-2
CAUTION!
The radiographic system PRS 500 E is, as a medical electrical electric device,
subject to particular precautionary measures in regard to EMC and is required
to be installed and prepared for initial use as described within the
accompanying documents.
CAUTION!
Mobile HF-Communication devices shouldn’t be used closer than 30cm (12
Inch) to the marked parts and cables of the PRS 500 E. Disregarding this can
cause a decrease in the performance features of the device.
CAUTION!
The X-ray generator integrated into the radiographic system PRS 500 E sends
out electromagnetic waves during operation, which could cause interference
with other devices.
For EMC guidelines and manufacturers declaration for the generator
according to EN 60601-1-2, see the separate User Manual for the
corresponding generator.
