2000 mm x 755 mm, optional
Patient load, max 230 kg TP composite fibre (standard)
250 kg TP carbon fibre
Table top height: 589mm - 876mm
Table top movement, transvers (from the mid-position): ± 150 mm
Table top movement longitudinal (from the mid-position): ± 470 mm (TP 2260mm) / ±
330mm (TP 2000mm)
The brakes of the tabletop are used electro-mechanic.
Detailed information please find in the enclosed User Manual, Technical Description of the PROGNOST
E.
7.3 Bucky, Grid entity
Longitudinal travel: 542 mm
Min. distance Bucky center to table head end: 330 mm
Min. distance Bucky center to table foot end: 440 mm
Table top - film-distance: 67 mm
The Bucky, Grid entity and the measure chambers are connected to the generator.
Detailed information please find in the enclosed User Manual, Technical Description of the Bucky, Grid
entity.
7.4 X-ray tube column
Focal spot vertical travel - horizontal X-ray beam: 294 – 1882.5mm
Focal spot vertical – film distance (standard PROGNOST E): max. 1364.5mm
Focal spot vertical – table top distance (standard PROGNOST E): max. 1297.5mm
Rotation X-ray tube assembly around horizontal support arm: ± 180°
detents at: - 90°, 0°, + 90°, 180°
Vertical travel supporting arm: 1588.5mm
Tube stand longitudinal travel: 1411mm
Tube stand longitudinal travel with rail extension FFD 3m: 2078.5 mm
Detailed information please find in the enclosed User Manual, Technical Description of the PROGNOST
SH.
7.5 Vertical X-ray system image receptor stand
Standard
Column height: 2190mm
Vertical shift film center: 385mm - 1865mm
The Bucky, Grid entity and the measure chambers are connected to the generator.
Detailed information please find in the enclosed User Manual, Technical Description of the PROVERT.
7.6 Attenuation Equivalent
WARNING!
