~ 37 ~
)?<5>?94(5<51C5>9D91D9>75F9351B4
95<4-9B9>7<53DB931<)@5396931D9?>C E=@5B)5DD9>7C
H@1>45B?1B4
#
()9C@<1I
&1>5<
<53DB931<(5AE9B5=5>DC
@@<9312<56?B+"N@@B?F54
)ICD5=C%><I
E=@5B)5DD9>7C
E=@5B"?31D9?>C
(5<51C9>79B3E9DC)?<5>?94(5<51C9>7
9B3E9DC1B5&?G5B"9=9D54
Maximum (2) conductor feed cable
impedance
0.6 OHM= #10 AWG - 300 FEET
#12 AWG - 190 FEET
#14 AWG - 120 FEET
Electrical - Initiating Device Cirucit
Voltage Standby 22VDC
Current to Insure Alarm 11mA
Less than 1.5K Ohm loop resistance maximum to insure alarm
End-of-Line Resistor (detection zone) ELR-4.7K 1/2 Watt, 5%
Electrical - Solenoid Release Circuit
Voltage Standby 0.87VDC @ 1K Ohm
Voltage Alarm 26VDC
Current Alarm 0.7 AMp Nominal
Conditioning Resistor (solenoid) 1K ohm, 1 Watt, 5%
MJ1
Jumper is placed across header MH1 pins 1 & 2 to inhibit SOL & IDC
indicators during system alarm state. Jumper is placed across pins 2 & 3
for active trouble indicators during system alarm state.
MJ2 or
MJ3
Jumper is placed across MH2 header for signal input release activation for
Solenoid Release circuit. For cross-zoned activation Jumper is installed
across MH3.
MJ4 -
MJ7
Remove jumpers across headers MH4 & MH5 and place jumpers across
MH6 & MH7 for alarm zone operation. Place jumpers across MH4 & MH5
and remove jumpers across MH6 & MH7 for supervisory zone operation
MJ8
Jumper across MH8 pins 2 & 3 for all solenoid deluge valves other than the Star
D module, which must have jumper placed across pins 1 & 2
MJ9
MH9 pins 1 & 2 installed when iniating device circuit is used as a detection zone.
Place across pins 2 & 3 when used as a supervisory zone
