Protectowire 2000 FireSystem - Solenoid Release Card Jumper Settings

RS-1
MJ5
MJ4
MJ7
MJ6
MJ2
MJ3
MJ9
MJ1
MJ8
~ 38 ~
(5<51C9>79B3E9DC)?<5>?94(5<51C9>7
9B3E9DC1B5&?G5B"9=9D54E><5CC)D1B
LMB?E@F1<F5C1B5EC54*85>39B
3E9DC1B53?>C945B54>?>@?G5B<9=9D54
Maximum (2) conductor feed cable
impedance
0.6 OHM= #10 AWG - 300 FEET
#12 AWG - 190 FEET
#14 AWG - 120 FEET
)?<5>?94(5<51C5>9D91D9>75F9351B4
95<4-9B9>7<53DB931<)@5396931D9?>C E=@5B)5DD9>7C
()9C@<1I
&1>5<
H@1>45B?1B4
#
@@<9312<56?B#N@@B?F54
)ICD5=C%><I
E=@5B"?31D9?>C
E=@5B)5DD9>7C
<53DB931<(5AE9B5=5>DC
#
A5
A6
ELR-4.7K
1/2 W
2
#
1
<53DB931<)?<5>?94(5<51C59B3E9D
Voltage Standby 0.87VDC @ 1K Ohm
Voltage Alarm 26VDC
Current Alarm 0.7 AMp Nominal
Conditioning Resistor (solenoid) 1K ohm, 1 Watt, 5%
# 
Jumper is placed across header MH1 pins 1 & 2 to inhibit SOL & IDC
indicators during system alarm state. Jumper is placed across pins 2 & 3
for active trouble indicators during system alarm state.
# ?B
# 
Jumper is placed across MH2 header for signal input release activation for
Solenoid Release circuit. For cross-zoned activation Jumper is installed
across MH3.
# 
# 
Remove jumpers across headers MH4 & MH5 and place jumpers across
MH6 & MH7 for alarm zone operation. Place jumpers across MH4 & MH5
and remove jumpers across MH6 & MH7 for supervisory zone operation
# 
Jumper across MH8 pins 2 & 3 for all solenoid deluge valves other than the Star
D module, which must have jumper placed across pins 1 & 2
# 
MH9 pins 1 & 2 installed when iniating device circuit is used as a detection zone
Place across pins 2 & 3 when used as a supervisory zone
<53DB931<>9D91D9>75F9359B3E9D
Voltage Standby 22VDC
Current to Insure Alarm 11mA
Less than 1.5 K Ohm loop resistance maximum to insure alarm
End-of-Line Resistor ELR-4.7K, 1/2 Watt, 5%
FM approved Solenoid Groups Groups A thru K
Fuse (F1) used with Star D (Group C valve only 4 Amp Slo-Blo
