APPENDIX A (continued)
Important: consult manufacture cut-sheet for actual current draw
* - Indicates Field Selectable Device
NAC type Model / Series Average Current
* RSD24-75110 .250 Amps
* RSD24-153075
* RSB24-153075
RSD24-110 .200 Amps
Temporal Module TMP1-3A .025 Amps
Synchronization Module SMS1-3A .009 Amps
Conical Strobe Light SL-5 Series .25 Amps
Mini Horn * MIZ Series .017 Amps
Multitone Electronic
Appliance
* AMT Series .098 Amps
Motor Bell MB Series .030 Amps
Explosion Proof Bell CSX10 &CVX10 .500 Amps
Strobe Light RSSR Series .308 Amps
E70 Series .293 Amps
ET70 Series .171 Amps
E90 Series .333 Amps
ET90 Series .238 Amps
RSS Series
RSSP Series
* AS Series .277 Amps
AH Series .047 Amps
* CH70 Series .161 Amps
* CH90 Series .238 Amps
* NS Series .183 Amps
* NS4 Series .206 Amps
Weather Proof Strobe RSSWP Series .102 Amps
ASWP Series .145 Amps
AHWP Series .041 Amps
Weather Proof
Multitone Strobe
MTWP-24 Series .126 Amps
Weather Proof
Multitone Horn
MT-24 Series .040 Amps
Weather Proof
Speaker Strobe
ET70WP Series .102 Amps
SM Series .028 Amps
DSM Series .035 Amps
Weather Proof
Audible/ Visual Combo.
24V-MTWP Series .145 Amps
Vandal Resistant
Speaker Strobe
ET-1080 .200 Amps
Note: Under a Sprinkler Supervisory Condition, the assigned Notification Appliance Circuit must have a distinct
output signal from all other output notification circuits, Therefore a Temporal Module from Appendix A
must be added.
Note Wheelock Synch module DSM-12/24-R must be used for synchronization of Horn / Strobes.
Amesco
Wheelock
Strobe Light Retrofit
Speaker / Strobe
Strobe Plates
Audible Strobe
Chime Strobe Combination
Horn Strobe Appliance
Weather Proof
Audible Strobe
Synchronization Module
.333 Amps
.114 Amps
