Page 11
ENTER SETUP
PASSWORD: 0000
Password error.
Retry or press ESC.
SETUP: TECH
1: EXIT >
2: RESET DETECTOR
3: DETECTOR TYPE
Password Entry Screen Password Error Screen
Menu Screen
Use the left and right navigation buttons to select each character and th eup and down navigation buttons to
change the character. Once all characters have been entered press the center navigation button labled OK to
access the menu.
Entering an incorrect password will produce a password entry error and the user will be returned to the pass-
word entry screen. Press the escape ESC at any time to return to the main display.
The CTM-530 is supplied from the factory with default passwords for the user and technician level. During
initial setup it is recommended the technician level password be set to a new value to preevent unauthorized
access to the settings. The User level password can also be set to a new value at the installers discression but is
not require din most cases.
Default User level password = 1000
Default Technician level password = 2000
Once the correct user level password has been entered the setup menu will be displayed. The current user
level will be shown in the setup menu heading as seen below. The available menu items are numbered and
can be accessed by using the up and down navigation keys. The “>” symbol indicates the currently selected
menu item.
The setup menu can be exited at any time by either pressing the “ESC” keyor by selecting the “1: EXIT”
menu item and then pressing hte “OK” key. While accessing the setup menu the inputs will remain inactive.
After 30 seconds of inactivity the module will automatically exit the setup menu and resume normal opera-
tion.
Resetting the Detector - Once an alarm or short fault condition has been detected the module status will
remain in that condition until the detector has been reset. To reset the detector enter the setup menu and
select the “2: RESET DETECTOR” option.
