Protelex ICM-X22 - Ice Cream Machine Connect Line Diagram

www.nkprotelex.com
15
F09
Factory
parameters
Air pump start
mode
ON: press wash or
produce key to start
OFF: start when the ice
cream discharge
ON
Warning: This parameter only applies to FSAST_GL002_03D intelligent display, all
parameters of the ice cream machine have been adjusted well, the user cannot change
the parameters unless communicate with manufacturers.
10. Ice Cream Machine Connect Line Diagram
