Proto Rize - Rize Bolt O-Ring List

16
17
W W W . D Y E P A I N T B A L L . C O M W W W . D Y E P A I N T B A L L . C O M
RIZE
™
BO LT
ASSEMBLY A ND MAI NTENA NC E
67
1 1 1
4
1
2
1
4
1 0 20 N 70
2 0 17 N 70
3 0 15 N 70
4 0 14 N 70
5
6
7
0 0 9 N 70
0 13 x2mm N 90
RAIL™ BOLT O-RING LIST
RIZE
™
BO LT
ASSEMBLY A ND MAI NTENA NC E
00 9
3
MAINTENANCE
If the RIZE
™
BOLT is not kept clean
and well lubed, you will either start
seeing erratic velocity, leaks or over
long period of time, physical
damage to the RIZE
™
BOLT
components.
For troubleshooting leaks a
nd other bolt problems, consult the
troubleshooting section at the end of this manual.
55
Bolt Front Bumper
The basic maintenance for the RIZE™ BOLT is to clean all surfaces of
dirt, broken paint or other debris, check for any wear and tear on
the O-rings and changing them if needed, and finally applying
a thin coat of DYE Slick Lube on all surfaces. Before installing
the RIZE™ BOLT back to the RIZE™ marker check that the
bolt moves freely without a lot of friction and
make sure all pieces are threaded
together snugly!.
