PROVA 21 - Specifications: AC Current Harmonics, PF, Phase Angle, Frequency; Harmonics of AC Current (Magnitude); Power Factor, Phase Angle, and Frequency Specs

28
Harmonics of AC Current in Magnitude (1 to 99
th
order, minimum current at 50 or
60 Hz is greater than 100mA for mA range, and greater than 1A for A range)
Model 19, 21, 23
Range Resolution Accuracy
1 – 10
th
reading in mA: ±1% of reading ±2mA
reading in A: ±1% of reading ±0.3A
11 – 20
th
reading in mA: ±7% of reading ±2mA
reading in A: ±7% of reading ±0.3A
21 – 50
th
reading in mA: ±15% of reading ±3mA
reading in A: ±15% of reading ±0.3A
51 - 99
th
0.01mA /
0.1mA /
0.001A /
0.01A
reading in mA: ±35% of reading ±3mA
reading in A: ±35% of reading ±0.3A
Power Factor (PF, ACV > 4V, AC mA > 1mA, AC A > 0.04A, Watt > 50 digits)
Model 21, 23
Range Resolution Accuracy
0.000 – 1.000 0.001 ±0.04
Phase Angle (Φ, 50 or 60Hz)
Model 21, 23
Range Resolution Accuracy
-180° to 180° 0.1° ± 2°
0° to 360° 0.1° ± 2°
If function of AUTO Hz is selected, add 2° error to the accuracy.
Frequency (Hz)
Model 19, 21, 23
Range Resolution Accuracy of Readings Allowed Input
mA(45 – 65Hz) 0.1Hz ± 0.5Hz 20mA to 1.2A
A(45 - 65Hz) 0.1Hz ± 0.5Hz 1A to 100A
Sensitivity (PROVA 19, 21): > 20mA for mA range, > 1A for A range, and > 50V
Sensitivity (PROVA 23): > 20mA for mA range, > 3A for A range, and > 50V
