PROVA 21 - Specifications: Distortion, Peak Value, Crest Factor; Total Harmonic Distortion (THD-F) Specifications; Peak Value and Crest Factor Specifications

29
Total Harmonic Distortion (THD-F with respect to the first (fundamental)
harmonics, min. value in the range from 45 to 65Hz is greater than AC 80V, greater
than 1A for A range, and greater than 100mA for mA range. Calculation is done over
1 to 50
th
Harmonics. If the voltage or current is 0 in the range from 45 to 65Hz, all the
percentage (%) display is 0)
Model 19, 21
Range (45~65Hz) Resolution Accuracy
0.0 – 10.0 % 0.1% ± 2%
10.0 – 40% 0.1% ±5% of reading ± 5%
40 – 100% 0.1% ±10% of reading ± 10%
100 – 999.9% 0.1% ±20% of reading
Model 23
Range (45~65Hz) Resolution Accuracy
0.0 – 20.0 % 0.1% ± 2%
20.0 – 100% 0.1% ±3% of reading ± 5%
100 – 999.9% 0.1% ±10% of reading ±10%
Peak Value of AC Periodic Voltage (peak value > 10V) or AC Periodic Current
(peak value > 10mA for mA range and peak value > 0.5A for A range) for
continuous waveform except for square wave:
Model 19, 21, 23
Range Sampling Time Accuracy of Reading
50 Hz 39 μs ± 5% ± 30 digits
60 Hz 33 μs ± 5% ± 30 digits
Crest Factor (C.F.) of AC Voltage (peak value > 10V) or AC Current (peak value
> 10mA for mA range and peak value > 0.5A for A range) for continuous
waveform except for square wave:
Model 19, 21, 23
Range (45~65Hz) Resolution Accuracy of Readings
1.00 – 99.99 0.01 ± 5% ± 30 digits
