Model:
1. Day Indicator - Displays the day of the week.
2. Flame Symbol – Displayed when the thermostat is calling for heat and flashes when
optimum start is active.
3. Clock - Time displayed in 24 hour format.
4. Holiday – Displayed when the thermostat is in holiday mode.
5. Until & Hold Left - ‘Until’ displayed during a temperature override. ‘Hold Left’ appears
when a temperature hold is active, plus the remaining time will be shown.
6. Frost Icon– Displayed when frost protection is enabled.
7. Floor/Room Temp & Set - Indicates the displayed sensor mode and when changes are
being made to the current set point.
8. Program Indicators - Displayed during programming to show which period is
being altered.
9. Main Menu – Highlighted text indicates selected option.
10. Keypad Lock Indicator – Displayed when the keypad is locked.
11. Temperature – Displays the current sensor temperature.
12. Temperature Format - Degrees Celsius or Fahrenheit.
13. Floor Limit Symbol – Displayed when the floor probe has reached the floor
temperature limit configured in the setup menu.
14. Time/Day/Month/Year - Displays when setting the Clock/Calender or a Holiday Period.
LCD Display
