prowarm ProDigital - Wiring Diagramm - Time Clock Mode

Section Header
34
Model:
Wiring Diagram - Time Clock Mode
This product must only be installed by a qualified electrician
and comply with local installation regulations.
MAINS SUPPLY
RCD
Not used.
230VAC
NNTR
LOAD
L
Floor
Sensor
1-
L N
LOAD 16 AMP MAX
Model: ProDigital
™
