VP Keypad Access Device
26
114A3868.E rev. 7-2017
Standard Display Messages
The standard display message for the VP keypad when no keys
have been pressed is the date and time as shown.
Fri, 08 / 01 / 08
12 : 13 PM
Depending on how the system is configured, the user will have an
access code to enter, or a magnetic stripe card to swipe. When the
user approaches the keypad, the standard display message will be
shown on the display.
The display and keypad are backlit at a low level to conserve power
when the device is not in use. This low level of light is sufficient to
read the display at night. As soon as a customer presses the
* key,
the display returns to full brightness.
Access Codes and Cards
To enter an access code, the user presses *. The following message
will be displayed.
* PLEASE ENTER *
ACCESS CODE
The user enters their access code using the touch pad and presses
the
# key. The keypad sends the code to the controller and waits
for a response while the keypad goes through the security checks
described in “Security Checks” on page 27 . The message on
the display changes to the following while waiting for a response.
* PLEASE WAIT *
VERIFYING ACCESS
To use magnetic stripe cards, the user swipes their card through the
slot in the card reader. The magnetic stripe on the card must be
aligned to pass through the slot facing the left side of the reader.
