2.8.3 Lower Range Limit for Dose per Pulse
Measurement
Table 3 shows the lower range limits for dose per
pulse measurements. If the measured value drops
below the lower limit, DIADOS E will display LO
instead of the measured value.
Two asterisks "**" appearing next to a measuring
value indicate an elevated measuring error due to
insufficient resolution.
f
[Hz]
T
pulse
[ms]
Low
[nGy/pulse]
Medium
[µGy/pulse]
High
[µGy/pulse]
150
3.3
2
0.1 ... 1
9
5.5
4
0.12
0.07
0.07
11.0
6.0
3.5
100
5
3
0.1 ... 1
10
6
3.5
0.1
0.1
0.1
13
8
5
50
10
5
0.1 ... 3
15
7
3.5
0.2
0.2
0.2
24
13
10
25
20
10
0.1 ... 3
26
12
5
0.5
0.4
0.4
52
25
15
10
20
10
0.1 ... 1
26
10
5
1
1
0.5
50
50
5
Table 3: Lower range limit for dose per pulse measurement. Typical values at a minimum resolution of 1% in
dependence of the measurement range. We assume that the pulse duration T
pulse
is shorter than the
interval between two pulses.
